Siemens Hobs

Siemens iQ500 Induction Hob 80cm | ED851FWB5E

Siemens iQ500 80cm InductionAir Venting Hob Black Glass | ED851FQ15E esign 3 sided bevelled frameless finish 80 cm: space for 4 pots or pans. Flexibility of cooking zones 2 Combi zones : use bigger cookware by connecting two classic cooking zones into one large zone. Cooking zone front left: 190 mm, 210 mm, 2.2 KW (max. power 3.7 KW) Cooking zone rear left: 190 mm, 210 mm, 2.2 KW (max. power 3.7 KW) Cooking zone rear right: 190 mm, 210 mm , 2.2 KW (max power 3.7 KW) Cooking zone front right: 190 mm, 210 mm, 2.2 KW (max. power 3.7 KW) Usage convenience touchSlider control: directly control the power with the imprinted touch bar. 17 power levels: precisely adapt the heat with 17 power levels (9 main levels and 8 intermediate levels). Timer for all zones : switches off the cooking zone at the end of the time set (e.g. for boiled eggs). Acoustic Signal : an alarm sounds at the end of the time set (e.g. for pasta). Time saving & efficiency Power boost setting : boil water faster thanks to 50% more energy than at the highest standard level. 2-steps: increase or decrease the power level simply by moving the pot forwards or backwards. quickStart function: when switching on, the hob automatically selects the cooking zone with cookware (when placed on a zone whilst the hob is off). reStart function: in case of unintentional switch-off, this feature restores all previous settings by switching on the hob again within 4 seconds Safety 2 stage residual heat indicators: indicates which cooking zones are still hot or warm. Control panel lock: prevent unintended activation of the hob. Control panel pause: wipe overboiled liquids without unintentionally changing settings (blocking all touch buttons for 30 seconds). Main on/off switch: switch off all cooking zones at the touch of a button. Automatic safety switch off: for safety reasons, heating stops after a preset time if not used (possible to customise). Energy Consumption Display: shows the electricity consumption of the last cooking process. Installation Dimensions of the product (HxWxD mm): 223 x 802 x 522 Required niche size for installation (HxWxD mm) : 223 x 750 x (490 - 490) Min. worktop thickness: 16 mm Connected load: 7.4 KW Connection current management (20, 16, 13, 10 Amps options): limit the maximum power if needed (depends on fuse protection of electric installation). Power cord: 1.1 m, Cable included in packaging Integrated ventilation downdraft system Induction cooktop with fully integrated high-performance downdraft extractor. Suitable for ducted or recirculated extraction configuration (incl. differentiated software modes). Respective mandatory installation accessories required: - HZ9VEDU0 for ducted extraction. - Starter kit HZ9VRUD0 for unducted recirculation with cleanAir odour filters. - HZ9VRPD0 for fully ducted and partly-ducted recirculation with cleanAir odour filters. - HZ9VEDU0 for ducted extraction. - HZ9VRPD0 for fully ducted and partly-ducted recirculation with cleanAir odour filters. Starter kit HZ9VRUD0 for unducted recirculation with cleanAir odour filters. Aesthetically integrated fully flush air intake design with floating, heat resistant glass ceramics element for free movement and placement of cookware. Ventilation system with 9 electronically controlled fan power levels and 2 Boost-/Intensive fan power levels (with automatic revert) via touchSlider control user interface: - Automatic switch-on of ventilation system when a cooking zone is used. - Automatic delayed shut-off after cooking to erase residual odors after cooking (in specific ultra low-noise fan level, 12min in ducted extraction, 30min in recirculated extraction, can be shut-off manually). - Fully manual control possible via touchSlider control. - Automatic switch-on of ventilation system when a cooking zone is used. - Automatic delayed shut-off after cooking to erase residual odours after cooking (in specific ultra low-noise fan level, 12min in ducted extraction, 30min in recirculated extraction, can be shut-off manually). - Fully manual control possible via touchSlider control. High-performance, low-noise motor with energy-efficient BLDC-technology. High extraction rates at very low noises with pleasant noise frequencies through psycho-acoustically and aerodynamically optimised interior with enclosed, hidden motor. Highly pressure-drop resistant even with longer and more complex ducting systems. Easy-to-detach and easy-to-clean grease filter and liquid collector unit: - Convenient one-hand removal of unit via floating glass ceramics handle. - Integrated, large-scale, high performance stainless-steel grease filters with 12 filtration layers and one black top layer for enhanced aesthetical integration. Grease filtration efficiency of 94 %. - All parts of the unit are easy-to-clean, fully dishwasher safe and heat resistant. - (Upper) Liquid collector unit with 200ml of capacity for standard accidental spillages or cooking condensate. - Powerful drainage system for spillages that exceed 200ml of liquids. - Liquid safety collector with additional capacity of 700ml for more severe accidental situations. Dishwasher safe. Easily accessible and detachable from below. - Overall capturing capacity of 900ml (200ml + 700ml). - Watertight motor system. - Convenient one-hand removal of unit via floating glass ceramics handle. - Integrated, large-scale, high performance stainless-steel grease filters with 12 filtration layers and one black top layer for enhanced aesthetical integration. Grease filtration efficiency of 94 %. - All parts of the unit are easy-to-clean, fully dishwasher safe and heat resistant. - (Upper) Liquid collector unit with 200ml of capacity for standard accidental spillages or cooking condensate. - Powerful drainage system for spillages that exceed 200ml of liquids. - Liquid safety collector with additional capacity of 700ml for more severe accidental situations. Dishwasher safe. Easily accessible and detachable from below. - Overall capturing capacity of 900ml (200ml + 700ml). - Watertight motor system. Ventilation system performance: - Extraction performance in ducted extraction (according to EN 61591): min. normal setting 154 MQH , max. normal setting 500 MQH, max. Boost-/Intensive setting 622 MQH. - Extraction performance in recirculated extraction (according to EN 61591): min. normal setting 150 m3/h , max. normal setting 500 m3/h , max. Boost-/Intensive setting 615 m3/h. - Noise level in ducted extraction (Sound power level according to EN 60704-3): min. normal setting 42 dB re 1 pW, max. normal setting 69 dB re 1 pW, max. Boost-/Intensive setting 74 dB re 1 pW. - Noise level in recirculated extraction (Sound power level according to EN 60704-3. ): min. normal setting 41 dB re 1 pW, max. normal setting 68 dB re 1 pW, max. Boost-/Intensive setting 72 dB re 1 pW. - Grease filter efficiency (according to EN 61591) 94 %. All performance data is preliminary and based on latest test results with advanced prototypes and will be updated with tests from final products. - Extraction performance in ducted extraction (according to EN 61591): min. normal setting 154 m3/h , max. normal setting 500 m3/h , max. Boost-/Intensive setting 622 m3/h . - Extraction performance in recirculated extraction (according to EN 61591): min. normal setting 150 m3/h , max. normal setting 500 m3/h , max. Boost-/Intensive setting 615 m3/h. - Noise level in ducted extraction (Sound power level according to EN 60704-3): min. normal setting 42 dB  re 1 pW, max. normal setting 69 dB  re 1 pW, max. Boost-/Intensive setting 74 dB  re 1 pW. - Noise level in recirculated extraction (Sound power level according to EN 60704-3. ): min. normal setting 41 dB  re 1 pW, max. normal setting 68 dB  re 1 pW, max. Boost-/Intensive setting 72 dB  re 1 pW. - Grease filter efficiency (according to EN 61591) 94 %. All performance data is preliminary and based on latest test results with advanced prototypes and will be updated with tests from final products. Consumption data and energy efficiency (according to Regulation (EU) No 65/2014): - Energy Efficiency Class: B (at a range of energy efficiency classes from A+++ to D). - Fluid Dynamic Efficiency: A . - Average energy consumption: 57 . - Grease filtration effciency class: B . - Noise min. normal setting & max. normal setting: 42 dB & 69 dB . - Energy Efficiency Class: B (at a range of energy efficiency classes from A+++ to D). - Fluid Dynamic Efficiency: A . - Average energy consumption: 57 . - Grease filtration effciency class: B . - Noise min. normal setting & max. normal setting: 42 dB  & 69 dB . 2 x 2 sets of directly integrated, high-performance cleanAir odour filters (in recirculation configuration). - Optimised odour reduction performance for cooking applications with complex odour molecules (e.g. fish). - Large scale filter surface with high odour reduction capabilities. - Lifetime of 360 hours of cooking (non-regenerative). - Low-noise filters with optimised psycho-acoustics. - Easy-to-access and easy-to-remove from above. - Replenishment cleanAir filter set HZ9VRCR0. For ducted extraction configuration: 2 x 2 sets of directly integrated, high-performance low-noise acoustic filters for significantly lower noise and improved psycho-acoustics. - Optimised odour reduction performance for cooking applications with complex odour molecules (e.g. fish). - Large scale filter surface with high odour reduction capabilities. - Lifetime of 360 hours of cooking (non-regenerative). - Low-noise filters with optimised psycho-acoustics. - Easy-to-access and easy-to-remove from above. - Replenishment cleanAir filter set HZ9VRCR0. For ducted extraction configuration: 2 x 2 sets of directly integrated, high-performance low-noise acoustic filters for significantly lower noise and improved psycho-acoustics. Planning & installation notes Suitable for ducted or recirculated extraction configuration (incl. differentiated software modes). Respective mandatory installation accessories required: - HZ9VEDU0 for ducted extraction. - Starter kit HZ9VRUD0 for unducted recirculation with cleanAir odour filters. - HZ9VRPD0 for fully ducted and partly-ducted recirculation with cleanAir odour filters. - HZ9VEDU0 for ducted extraction. - HZ9VRPD0 for fully ducted and partly-ducted recirculation with cleanAir odour filters. Starter kit HZ9VRUD0 for unducted recirculation with cleanAir odour filters. Planning suggestions: - Installation is possible in island as well as wall oriented configurations. - The product complies with the Needle Flame Test (according to IEC 60695-5-11), the V2 flammability class (according to UL94) and the B1 building material class (DIN 4102-1). The starter kit HZ9VRUD0 for unducted recirculation complies with these standards as well. - The max. immersion depth is 223mm below glass for top mounted appliances and 227mm for flush installed appliances. - The appliance must be freely accessible from below (i.e. for accessing the lower liquid safety collector). - No false floor is necessary below the cooktop with integrated downdraft ventilation system. The drawers and/or shelves in the floor unit must be removable. The backpanel of the floor unit can be kept - only a cut-out for the air outlet is needed (position and size can be taken from the installation instructions). - The "Plug 'n Play" starter kit HZ9VRUD0 for unducted recirculation requires a vertical aperture of min. 25mm behind the backpanel of the furniture. Suggested for ideal performance are 50mm. - The minimum worktop thickness is 16mm for top mounted and flush installed appliances with the standard installation system. Installation in even thinner worktops is also possible with the spare part: content 626792. - The overall appliance weight is 26kg - the bearing capacity and stability, in the case of very thin worktops in particular, must be supported using suitable substructures. The overall appliance weight and the worktop manufacturer's structural integrity specifications are to be taken into account. - The "Plug 'n Play" starter kit HZ9VRUD0 for unducted recirculation enables easy and quick installations and can be planned in all worktop depths ≥60cm. For ducted installations - in ducted extraction (HZ9VEDU0) as well as fully or partly ducted recirculation (HZ9VRPD0) - a worktop depth of ≥70cm is required. - For partly ducted and unducted recirculation extraction installations, a return-flow aperture of ≥400cm² is to be respected in the plinth area. The aperture can be realized via outlet grids, lamella grids or subtly shortened plinths depending on the assortment of the kitchen furniture manufacturer. - The air outlet on the backside of the appliance can directly be accessed with a male flat duct element (DN 150). - The pressuredrop resistant blower allows longer and more complex ductings up to 8m with three 90° bows while keeping sufficient performance. - When installing a ventilation hood with ducted extraction and a chimney-vented fireplace, the power supply line of the appliance needs a suitable safety switch. This is not required for configurations in recirculated extraction. -  In ducted extraction configuration a one-way flap (or backflow trap) with a maximum opening pressure of 65Pa should be installed. - Installation is possible in island as well as wall oriented configurations. - The product complies with the Needle Flame Test (according to IEC 60695-5-11), the V2 flammability class (according to UL94) and the B1 building material class (DIN 4102-1). The starter kit HZ9VRUD0 for unducted recirculation complies with these standards as well. - The max. immersion depth is 223mm below glass for top mounted appliances and 227mm for flush installed appliances. - The appliance must be freely accessible from below (i.e. for accessing the lower liquid safety collector). - No false floor is necessary below the cooktop with integrated downdraft ventilation system. The drawers and/or shelves in the floor unit must be removable. The backpanel of the floor unit can be kept - only a cut-out for the air outlet is needed (position and size can be taken from the installation instructions). - The "Plug 'n Play" starter kit HZ9VRUD0 for unducted recirculation requires a vertical aperture of min. 25mm behind the backpanel of the furniture. Suggested for ideal performance are 50mm. - The minimum worktop thickness is 16mm for top mounted and flush installed appliances with the standard installation system. Installation in even thinner worktops is also possible with the spare part: content 626792. - The overall appliance weight is 26kg - the bearing capacity and stability, in the case of very thin worktops in particular, must be supported using suitable substructures. The overall appliance weight and the worktop manufacturer's structural integrity specifications are to be taken into account. - The "Plug 'n Play" starter kit HZ9VRUD0 for unducted recirculation enables easy and quick installations and can be planned in all worktop depths ≥60cm. For ducted installations - in ducted extraction (HZ9VEDU0) as well as fully or partly ducted recirculation (HZ9VRPD0) - a worktop depth of ≥70cm is required. - For partly ducted and unducted recirculation extraction installations, a return-flow aperture of ≥400cm² is to be respected in the plinth area. The aperture can be realized via outlet grids, lamella grids or subtly shortened plinths depending on the assortment of the kitchen furniture manufacturer. - The air outlet on the backside of the appliance can directly be accessed with a male flat duct element (DN 150). - The pressuredrop resistant blower allows longer and more complex ductings up to 8m with three 90° elbows while keeping sufficient performance. - When installing a ventilation hood with ducted extraction and a chimney-vented fireplace, the power supply line of the appliance needs a suitable safety switch. This is not required for configurations in recirculated extraction. -  In ducted extraction configuration a one-way flap (or backflow trap) with a maximum opening pressure of 65Pa should be installed.

Siemens 60cm Induction Hob EU631FEB1E Design Bevel front 60 cm: space for 4 pots or pans. Flexibility of cooking zones Cooking zone front left: 180 mm, 1.8 KW (max. power 3.1 KW) Cooking zone rear left: 180 mm, 1.8 KW (max. power 3.1 KW) Cooking zone rear right: 145 mm , 1.4 KW (max power 2.2 KW) Cooking zone front right: 210 mm, 2.2 KW (max. power 3.7 KW) Usage convenience touchSlider control: directly control the power with the imprinted touch bar. 17 power levels: precisely adapt the heat with 17 power levels (9 main levels and 8 intermediate levels). Timer for all zones : switches off the cooking zone at the end of the time set (e.g. for boiled eggs). Acoustic Signal : an alarm sounds at the end of the time set (e.g. for pasta). Time saving & efficiency Power boost setting : boil water faster thanks to 50% more energy than at the highest standard level. quickStart function: when switching on, the hob automatically selects the cooking zone with cookware (when placed on a zone whilst the hob is off). reStart function: in case of unintentional switch-off, this feature restores all previous settings by switching on the hob again within 4 seconds Safety 2 stage residual heat indicators: indicates which cooking zones are still hot or warm. Control panel lock: prevent unintended activation of the hob. Control panel pause: wipe overboiled liquids without unintentionally changing settings (blocking all touch buttons for 30 seconds). Main on/off switch: switch off all cooking zones at the touch of a button. Automatic safety switch off: for safety reasons, heating stops after a preset time if not used (possible to customise). Energy Consumption Display: shows the electricity consumption of the last cooking process. Installation Dimensions of the product (HxWxD mm): 51 x 592 x 522 Required niche size for installation (HxWxD mm) : 51 x 560 x (490 - 500) Min. worktop thickness: 16 mm Connected load: 4.6 KW Connection current management (20, 16, 13, 10 Amps options): limit the maximum power if needed (depends on fuse protection of electric installation). Power cord: 1.1 m, Cable included in packaging

Siemens iQ500 90cm 5 Ring Gas Hob - Tempered Black Glass | EP9A6SB90 General information Cooktop type Gas cooktop Hob type Gas Type of appliance width 90 cm Number of cooking zones 5 Power of the heating elements 1 x 1.0 KW, 1 x 3.0 KW, 1 x 4.0 KW, 2 x 1.75 KW Basic surface material Tempered glass Frame type Flush fitting Colour/material Black Energy efficiency of hob 56.0 % Dimensions Dimensions 58 x 915 x 520 mm Minimum height for installation 490 mm Maximum height for installation 502 mm Minimum width for installation 850 mm Maximum width for installation 852 mm Depth for installation 45 mm Dimensions PreviousNext Technische Daten Gas connection rating 11,500 W Nominal power 220-240 V Length electrical supply cord 150 cm Plug type no plug (electrical connection by electrician) Gas connection rear, right Gas type Nat gas H/E/(L) 20 (25) mbar Alternative gas type Liquid gas G30,31 28-30/37mbar Included user manuals [DE, EL, EN, ES, FR, HU, IT, NL, PL, PT, RO, RU, TR] Komfort Type of control setting devices sword knobs Electronic timer No Step Flame technology - 9 steps   stepFlame Technology Nine different flame settings let you set and adjust cooking heat instantly.   Yes Wok burner Yes dishwasher safe pan support   Dishwasher proof pan supports Our dishwasher-proof pan supports make cleaning up a breeze.   No Ignition system Yes Connectivity Home Connect No Control your hood with your Home Connect hob   cookConnect With cookConnect, your hood is connected to your hob for absolute ease of use.   No Safety Residual heat indicator without Safety device Flame failure safety device Type of safety device for gas Electromagnetic for each burner Design Tempered Glass surface, black frameless design: install the hob either flush or slightly raised on the worktop Cast iron pan supports with rubber feet Usage convenience Step Flame technology - 9 steps: precisely control and adjust the flame in nine defined levels. Design co-ordinated control dials: easily access dials in front with strong grip for effortless turning. Ignition via control dials: just push and turn the dials to ignite the flame. Burners and power 5 burner gas hob including Left: Wok burner up to 4 KW (depending on gas type) Center front: Economy burner up to 1 KW (depending on gas type) Center rear: Standard burner up to 1.75 KW (depending on gas type) Right rear: High-speed burner up to 3 KW (depending on gas type) Right front: Standard burner up to 1.75 KW (depending on gas type) Safety Flame failure safety device: prevents unwanted gas flow when flame goes out. Installation (gas types & measurements) Usable for: Nat gas L/LL G25/20mbar(DE) NG H/E 20mbar, E+ 20/25mbar Natural gas H 25 mbar (HU) Natural gas L 25 mbar (NL) Liquid gas G30,31 28-30/37mbar Liquid gas G30 37 mbar (PL) Liquid gas 50 mbar Factory set for connection to mains gas

Siemens iQ500 75cm Gas Hob | Black | EP7A6QB90   Gas cooktop with stepFlame Technology for precise flame control in nine steps. stepFlame Technology: precise heat control with nine different flame steps. This wok burner with 4.0 kW of power is ideal for a wide variety of foods, even in large quantities. Extremely heat-resistant and easy to clean – the modern glass ceramic surface. Fast cooking with even heat distribution: the wok burner with 4 kW. Cooking is a pleasure when you have the best ingredients. The wok burner combines the advantages of open-flame cooking with the benefits of the unique German gas technology from Siemens. The wok burner with 4 kW makes cooking faster, more convenient and more powerful – with a wide variety of foods, even in large quantities. Topsheet color black tempered glass The uniquely beautiful black tempered glass surface design. Precise heat control with nine different flame steps. Experience cprecise cooking with stepFlame Technology. Now you can adjust the flames on your cooktop in nine small steps to get exactly the heat you need and always the results you want. *Dispay not integrated in all appliances; depending on specific model Additional Information Design 752 mm Easy to clean Tempered Glass surface. Cast iron pan supports with rubber feet High efficiency burner set Special features Step Flame technology - 9 steps Design co-ordinated control dials Ignition via control dials Power and size: 5 burner gas hob including 1 rapid, 2 standard, 1 economy, 1 Wok Burner Left rear: Standard burner 1.75 KW Right rear: High-speed burner 3 KW Center front: wok burner 4 KW Left front: Economy burner 1 KW Right front: Standard burner 1.75 KW

Siemens iQ500 Gas Hob 60cm Hard Black Glass | EP6A6HB20 Design 590 mm Easy to clean Tempered Glass surface. Cast iron w rubber feet single High efficiency burner set Special features Step Flame technology - 9 steps Design co-ordinated control dials Ignition via control dials Power and size 4 burner gas hob including: 3 gas + wok Left rear: Standard burner 1.75 KW Right rear: WOK burner 3.5 KW Left front: Standard burner 1.75 KW Right front: Economy burner 1 KW Safety Features Factory set for connection to mains gas. Also usable for Nat gas L/LL G25/20mbar(DE) NG H/E 20mbar, E+ 20/25mbar Natural gas H 25 mbar (HU) Natural gas L 25 mbar (NL) Liquid gas G30,31 28-30/37mbar Liquid gas G30 37 mbar (PL) Liquid gas 50 mbar . For the use of these gas types nozzles need to be changed. Please check if the required nozzles are included (see Accessories). Flame failure safety device Accessories Nozzle set for LPG jets (28-30/37mbar) included. Nozzles for all other gas types can be ordered via the customer service. Technical information Power cord length 100 cm Min. worktop thickness: 30 mm Two possibilities for installation: -Flushline installation for stone or tiled work surfaces -Mounted on top of work surface

Siemens iQ700 80cm Induction Hob 5 Zone EX851FVC1E Design 3 sided bevelled frameless finish 80 cm: space for 5 pots or pans. Flexibility of cooking zones flexInduction zone: use cookware of any shape or size anywhere within the 40cm long zone. Cooking zone front left: 180 mm, 1.8 KW (max. power 3.1 KW) Cooking zone rear left: 145 mm, 1.4 KW (max. power 2.2 KW) Cooking zone middle: 240 mm, 2.2 KW (max. power 3.7 KW) Cooking zone rear right: 210 mm, 200 mm , 2.2 KW (max power 3.7 KW) Cooking zone front right: 210 mm, 200 mm, 2.2 KW (max. power 3.7 KW) Usage convenience touchSlider control: directly control the power with the imprinted touch bar. 17 power levels: precisely adapt the heat with 17 power levels (9 main levels and 8 intermediate levels). Timer for all zones : switches off the cooking zone at the end of the time set (e.g. for boiled eggs). Acoustic Signal : an alarm sounds at the end of the time set (e.g. for pasta). Time saving & efficiency Power boost setting : boil water faster thanks to 50% more energy than at the highest standard level. quickStart function: when switching on, the hob automatically selects the cooking zone with cookware (when placed on a zone whilst the hob is off). reStart function: in case of unintentional switch-off, this feature restores all previous settings by switching on the hob again within 4 seconds Cooking assistance fryingSensor with 4 temperature settings: prevents overcooking with the automatic temperature regulation of the integrated sensor. Safety 2 stage residual heat indicators: indicates which cooking zones are still hot or warm. Control panel lock: prevent unintended activation of the hob. Control panel pause: wipe overboiled liquids without unintentionally changing settings (blocking all touch buttons for 30 seconds). Main on/off switch: switch off all cooking zones at the touch of a button. Automatic safety switch off: for safety reasons, heating stops after a preset time if not used (possible to customise). Energy Consumption Display: shows the electricity consumption of the last cooking process. Installation Dimensions of the product (HxWxD mm): 51 x 802 x 522 Required niche size for installation (HxWxD mm) : 51 x 750 x (490 - 500) Min. worktop thickness: 16 mm Connected load: 7.4 KW Connection current management (20, 16, 13, 10 Amps options): limit the maximum power if needed (depends on fuse protection of electric installation). Power cord: 1.1 m, Cable included in packaging

Siemens iQ100 80cm 5 Zone Induction Hob | EH801FVB1E Design Flush fitting design/installation 80 cm: space for 5 pots or pans. Flexibility of cooking zones Cooking zone front left: 180 mm, 1.8 KW (max. power 3.1 KW) Cooking zone rear left: 145 mm, 1.4 KW (max. power 2.2 KW) Cooking zone middle: 240 mm, 2.2 KW (max. power 3.7 KW) Cooking zone rear right: 145 mm , 1.4 KW (max power 2.2 KW) Cooking zone front right: 210 mm, 2.2 KW (max. power 3.7 KW) Usage convenience touchSlider control: directly control the power with the imprinted touch bar. 17 power levels: precisely adapt the heat with 17 power levels (9 main levels and 8 intermediate levels). Timer for all zones : switches off the cooking zone at the end of the time set (e.g. for boiled eggs). Acoustic Signal : an alarm sounds at the end of the time set (e.g. for pasta). Time saving & efficiency Power boost setting : boil water faster thanks to 50% more energy than at the highest standard level. quickStart function: when switching on, the hob automatically selects the cooking zone with cookware (when placed on a zone whilst the hob is off). reStart function: in case of unintentional switch-off, this feature restores all previous settings by switching on the hob again within 4 seconds Safety 2 stage residual heat indicators: indicates which cooking zones are still hot or warm. Control panel lock: prevent unintended activation of the hob. Control panel pause: wipe overboiled liquids without unintentionally changing settings (blocking all touch buttons for 30 seconds). Main on/off switch: switch off all cooking zones at the touch of a button. Automatic safety switch off: for safety reasons, heating stops after a preset time if not used (possible to customise). Energy Consumption Display: shows the electricity consumption of the last cooking process. Installation Dimensions of the product (HxWxD mm): 56 x 792 x 512 Required niche size for installation (HxWxD mm): 56 x 796  x 516 Min. worktop thickness: 16 mm Connected load: 7.4 KW Connection current management (20, 16, 13, 10 Amps options): limit the maximum power if needed (depends on fuse protection of electric installation). Power cord: 1.1 m, Cable included in packaging For installation in stone, granitic or synthetic worktops. Other worktop materials require a suitability check with the worktop manufacturer.

Siemens iQ100 80cm Induction Hob 5 Zone EH845FVB1E Design All around trim 80 cm: space for 5 pots or pans. Flexibility of cooking zones Cooking zone front left: 180 mm, 1.8 KW (max. power 3.1 KW) Cooking zone rear left: 145 mm, 1.4 KW (max. power 2.2 KW) Cooking zone middle: 240 mm, 2.2 KW (max. power 3.7 KW) Cooking zone rear right: 145 mm , 1.4 KW (max power 2.2 KW) Cooking zone front right: 210 mm, 2.2 KW (max. power 3.7 KW) Usage convenience touchSlider control: directly control the power with the imprinted touch bar. 17 power levels: precisely adapt the heat with 17 power levels (9 main levels and 8 intermediate levels). Timer for all zones : switches off the cooking zone at the end of the time set (e.g. for boiled eggs). Acoustic Signal : an alarm sounds at the end of the time set (e.g. for pasta). Time saving & efficiency Power boost setting : boil water faster thanks to 50% more energy than at the highest standard level. quickStart function: when switching on, the hob automatically selects the cooking zone with cookware (when placed on a zone whilst the hob is off). reStart function: in case of unintentional switch-off, this feature restores all previous settings by switching on the hob again within 4 seconds Safety 2 stage residual heat indicators: indicates which cooking zones are still hot or warm. Control panel lock: prevent unintended activation of the hob. Control panel pause: wipe overboiled liquids without unintentionally changing settings (blocking all touch buttons for 30 seconds). Main on/off switch: switch off all cooking zones at the touch of a button. Automatic safety switch off: for safety reasons, heating stops after a preset time if not used (possible to customise). Energy Consumption Display: shows the electricity consumption of the last cooking process. Installation Dimensions of the product (HxWxD mm): 55 x 795 x 517 Required niche size for installation (HxWxD mm) : 55 x 780 x (500 - 500) Min. worktop thickness: 16 mm Connected load: 7.4 KW Connection current management (20, 16, 13, 10 Amps options): limit the maximum power if needed (depends on fuse protection of electric installation). Power cord: 1.1 m, Cable included in packaging

Siemens iQ100 60cm 4 Burner Gas Hob Stainless Steel | EB6B5PB60 Design Stainless steel surface cast iron finish pan supports with rubber feet Usage convenience Design co-ordinated control dials: access dials on the side with strong grip for effortless turning. Ignition via control dials: just push and turn the dials to ignite the flame. Burners and power 4 burner gas hob including: Left front: High-speed burner up to 3 KW (depending on gas type) Left rear: Standard burner up to 1.7 KW (depending on gas type) Right rear: Standard burner up to 1.7 KW (depending on gas type) Right front: Economy burner up to 1 KW (depending on gas type) Safety Flame failure safety device: prevents unwanted gas flow when flame goes out. Installation (gas types & measurements) Usable for: Nat gas L/LL G25/20mbar(DE) NG H/E 20mbar, E+ 20/25mbar Natural gas H 25 mbar (HU) Natural gas L 25 mbar (NL) Liquid gas G30,31 28-30/37mbar Liquid gas G30 37 mbar (PL) Liquid gas 50 mbar Factory set for connection to mains gas Nozzle set for LPG jets (28-30/37mbar) included. Nozzles for all other gas types can be ordered via the customer service. For nozzle change, please contact the customer service. Dimensions of the product (HxWxD mm): 56 x 580 x 510 Required niche size for installation (HxWxD mm) : 45 x 560 x (480 - 492) Min. worktop thickness: 30 mm Power cord: 1 m Connected load: 7.4 KW

Siemens iQ700 80cm 4 Zone Flex Induction Hob Black Glass | EX875KYW1E Design Side profiles 80 cm: space for 4 pots or pans. Flexibility of cooking zones 2 extended flexInduction zones: use cookware of any shape or size anywhere within the 40cm long zone or even place it laterally. Cooking zone front left: 230 mm, 200 mm, 2.2 KW (max. power 3.7 KW) Cooking zone rear left: 230 mm, 200 mm, 2.2 KW (max. power 3.7 KW) Cooking zone rear right: 230 mm, 200 mm , 2.2 KW (max power 3.7 KW) Cooking zone front right: 230 mm, 200 mm, 2.2 KW (max. power 3.7 KW) Usage convenience fullTouch TFT Display: easily operate the hob using the touch display and explore all available functions thanks to full-text information and images. 17 power levels: precisely adapt the heat with 17 power levels (9 main levels and 8 intermediate levels). Keep warm function: keep dishes warm at preset low power level. Timer for all zones : switches off the cooking zone at the end of the time set (e.g. for boiled eggs). Acoustic Signal : an alarm sounds at the end of the time set (e.g. for pasta). Count up timer : shows how much time has passed since starting the timer (e.g. for potatoes). Time saving & efficiency Power boost setting : boil water faster thanks to 50% more energy than at the highest standard level. panBoost: heat up pans faster than at the highest standard level while protecting the pan coating. powerMove plus: increase or decrease the power level simply by moving the pot forwards or backwards. flexMotion: when moving a pot to a different cooking zone, this feature transfers all previous settings to the new zone at the touch of a button. quickStart function: when switching on, the hob automatically selects the cooking zone with cookware (when placed on a zone whilst the hob is off). reStart function: in case of unintentional switch-off, this feature restores all previous settings by switching on the hob again within 4 seconds Cooking assistance cookControl Plus: easily find the right temperature setting for a certain dish in the touch display. cookingSensor Plus ready (sensor available as additional purchase): prevents overboiling of pots with the automatic temperature regulation of the sensor (attached to the pot). 5 frying and 5 cooking levels: prevents overcooking with the automatic temperature regulation of the integrated sensor.

Siemens iQ700 90cm Induction Hob 5 Zone EX975LVV1E Design Stainless Steel side trim with bevelled front edge 90 cm: space for 5 pots or pans. Flexibility of cooking zones 2 flexInduction zones: use cookware of any shape or size anywhere within the 40cm long zone. Triple ring zone: use regular up to extra large cookware (e.g. paella pans) on the expandable cooking zone. Cooking zone front left: 230 mm, 200 mm, 2.2 KW (max. power 3.7 KW) Cooking zone rear left: 230 mm, 200 mm, 2.2 KW (max. power 3.7 KW) Cooking zone middle: 320 mm, 260 mm, 210 mm, 3.3 KW (max. power 3.7 KW) Cooking zone rear right: 230 mm, 200 mm , 2.2 KW (max power 3.7 KW) Cooking zone front right: 230 mm, 200 mm, 2.2 KW (max. power 3.7 KW) Usage convenience Dual lightSlider: directly control the power on the two illuminated touch bars (invisible when switched off). 17 power levels: precisely adapt the heat with 17 power levels (9 main levels and 8 intermediate levels). Keep warm function: keep dishes warm at preset low power level. Timer for all zones : switches off the cooking zone at the end of the time set (e.g. for boiled eggs). Acoustic Signal : an alarm sounds at the end of the time set (e.g. for pasta). Count up timer : shows how much time has passed since starting the timer (e.g. for potatoes). Time saving & efficiency Power boost setting : boil water faster thanks to 50% more energy than at the highest standard level. panBoost: heat up pans faster than at the highest standard level while protecting the pan coating. powerMove plus: increase or decrease the power level simply by moving the pot forwards or backwards. quickStart function: when switching on, the hob automatically selects the cooking zone with cookware (when placed on a zone whilst the hob is off). reStart function: in case of unintentional switch-off, this feature restores all previous settings by switching on the hob again within 4 seconds Cooking assistance fryingSensor plus with 5 temperature settings: prevents overcooking with the automatic temperature regulation of the integrated sensor. Dish assistant: easily find the right temperature setting for a certain dish via the home connect app. Connectivity Home Connect - enables Remote Monitoring no matter where you are, with the easy-to-use Home Connect App: check if the hob is switched off even when not at home, and find recipes or additional functions in the Home Connect app. cookConnect - hood control (with Wi-Fi enabled hood): automatically activates the hood when cooking, thanks to the WiFi connection of hob and suitable hood. Safety 2 stage residual heat indicators: indicates which cooking zones are still hot or warm. Control panel lock: prevent unintended activation of the hob. Control panel pause: wipe overboiled liquids without unintentionally changing settings (blocking all touch buttons for 30 seconds). Main on/off switch: switch off all cooking zones at the touch of a button. Automatic safety switch off: for safety reasons, heating stops after a preset time if not used (possible to customise). Energy Consumption Display: shows the electricity consumption of the last cooking process. Installation Dimensions of the product (HxWxD mm): 51 x 912 x 520 Required niche size for installation (HxWxD mm) : 51 x 880 x (490 - 500) Min. worktop thickness: 16 mm Connected load: 11.1 KW Connection current management (20, 16, 13, 10 Amps options): limit the maximum power if needed (depends on fuse protection of electric installation). Power cord: 1.1 m, Cable included in packaging
